Bali® Classics™ One Inch Blind:

Top quality one inch horizontal aluminum window covering for commercial applications.

 Key Features:

  • Advanced Finishing Technology™

  • Lifetime warranty

  • Headrail: 1" high x 1 9/16" wide

  • Nominal .006" or .008" louver thickness

  • 21.5 mm ladder spacing



Product Overview:

The Bali Classics Mini Blind is a high quality mini blind that has been an industry standard for over 20 years. It provides excellent performance for very large windows and has a solid record for long lasting dependability. Available with a wide range of commercial options, the Bali Classics is a great choice for any commercial application. The Bali Classics headrail system is also used for our Special Shape, Dual Headrail Skylight and Incline Wire mini blind products.

Product Specifications:













 Product Specifications:


 A.
Bali® Classics™ One Inch Blind

Manufactured by Springs Industries
 B. Lifetime Warranty
 C. Materials:

•

Headrail: .025" thick phosphate treated steel. U-shaped, 1" high x 1 9/16" wide. All hardware enclosed in the headrail.


•


Tilter:
Clear polycarbonate, nylon gear acetal thermoplastic housing designed for smooth low friction operation.  Field replaceable.


•


Tilt Wand:
Solid, transparent with a hexagonal cross section .250" across points.


•


Cord Lock:
Stainless steel wear and floating shaft type locking pin. Crashproof.  Field replaceable.


•


Drums & Cradles:
Provided with each ladder, all mechanically locked into headrail.


•


Installation Brackets:
Standard hinged cover end support brackets of phosphate treated steel with prime coat of polyester baked enamel in color to match headrail.


•


Ladders (slat supports):
Braided ladder with adequate overlap of slats; standard spacing is 21.5 mm, optional 20 mm and 22.5 spacing is also available.


•


Slats:
Aluminum alloyed for maximum strength, flexibility and resistance to corrosion.  Nominally one inch wide, actual .991 inch (+.044 or -.000 inch).  Standard thickness is .006", optional .008".  Louvers shall have a pre-coating treatment to bond the polyester baked enamel finish coat the features our Advanced Finishing Technology (AFT) which provides a smoother, harder, less porous surface that provides anti-static performance to help repel dust and anti-microbial qualities to help resist fungal and bacterial growth.


•


Slat Design
(select one):
a. Unperforated
b. Perforated - slats are perforated with an openness factor of 6%. Available in 6 colors: White Satin, Alabaster, Brushed Aluminum, Smokey Gray, Char Brown, and Black Satin.


•


Bottomrail:
Enclosed tubular shade, .025" thick phosphate treated steel with prime coat of vinyl primer and finish coat of polyester baked enamel matching headrail and coordinating slat color.  Bottomrail shall be roll-formed with locking grove to receive dust cover.


•


Options:
a. Top Locking cord lock
b. Ring pull
c. Restrictive Cam Tilter
d. Special Installation Brackets
e. Cord Tilter
f.  Accent channels
